Polystyrene white
Temperature resistance max. 70°C







ABS grey
Temperature resistance max. 100°C







Polystyrene black
Temperature resistance max. 70°C






















Operating pressure
max. 0,8 bar







Medium
Air







Connection nozzle
tapered












Discover the METZGER TECHNIK® silencers & filters




Filter


  • PS

TYPE 30
Filter

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 6,0 10,5 14,5 21,0 26,0 28,5 30,5 32,0 -
Pressure side [l/min] 11,0 15,0 18,0 23,5 29,0 30,5 31,5 37,5 40,0


Single silencer without filter insert


  • PS

  • ABS

TYPE 49
Single silencer without filter insert

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 7,3 11,3 14,3 19,3 23,2 25,1 27,0 28,3 -
Pressure side [l/min] 5,4 9,0 12,3 18,3 24,0 26,1 28,3 30,4 -

  • PS

  • ABS

TYPE 51
Single silencer without filter insert with aluminum filter

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 5,0 10,5 12,5 15,5 23,0 26,0 27,5 29,5 30,0
Pressure side [l/min] 7,0 12,0 16,0 21,5 28,0 29,5 32,0 33,5 35,0


Silencer with filter insert


  • PS

  • ABS

TYPE 50
Silencer with filter insert

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 4,5 8,0 11,5 15,5 19,5 20,5 22,0 23,5 28,5
Pressure side [l/min] 5,0 10,0 12,5 15,5 17,0 19,0 19,5 20,0 27,0

  • PS

  • ABS



TYPE 60
Double silencer with filter insert and aluminum filter

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 3,0 5,5 8,0 11,0 14,5 16,0 17,0 18,5 21,0
Pressure side [l/min] 5,5 8,0 10,0 14,0 16,5 18,0 19,0 19,5 25,5

  • PS

  • ABS

TYPE 52
Silencer with 2 filter inserts

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 6,2 8,2 9,8 11,2 12,3 13,3 13,7 14,2 15,5
Pressure side [l/min] 4,1 6,6 9,6 14,6 18,7 21,9 23,8 24,9 32,6

  • PS

  • ABS

TYPE 63
Double silencer with 2 filter inserts

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 7,5 10,4 12,6 16,8 19,6 21,3 22,9 23,9 29,2
Pressure side [l/min] 3,7 6,8 10,8 14,2 19,4 21,4 23,4 24,8 18,4

  • PS

  • ABS

TYPE 61
Double silencer with 2 filter inserts and elbow connection piece

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 4,8 6,2 7,9 10,4 12,6 13,5 14,2 15,2 18,3
Pressure side [l/min] 2,4 5,0 7,1 9,2 11,8 12,7 13,5 14,7 18,4

  • PS

  • ABS

TYPE 62
Double silencer with 2 filter inserts and 2 elbow connectors

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 4,8 6,2 7,9 10,4 12,6 13,5 14,2 15,2 18,3
Pressure side [l/min] 2,4 5,0 7,1 9,2 11,8 12,7 13,5 14,7 18,4


Silencer with 4 filter inserts


  • PS

  • ABS

TYPE 64
Silencer with 4 filter inserts

Flow

Pressure [mbar] -10 -20 -30 -50 -70 -80 -90 -100 -140
Suction side [l/min] 4,1 5,5 7,0 9,8 11,2 12,4 12,8 13,9 15,4
Pressure side [l/min] 2,8 4,8 6,2 9,3 12,2 13,5 14,4 16,1 20,3









Possible areas of application & industries:
